Acura Integra (1992 – 1993) – wiring diagrams – power locks

Acura Integra (1992 – 1993) – wiring diagrams – power locks

Year of productions: 1992, 1993

Power locks

Acura Integra – wiring diagram – power locks

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
