Acura Integra (1997) – wiring diagrams – courtesy lamp

Acura Integra (1997) – wiring diagrams – courtesy lamp

Year of productions: 1997

Courtesy lamp

Acura Integra – wiring diagram – courtesy lamp (part 1)
Acura Integra – wiring diagram – courtesy lamp (part 2)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
