Acura Legend (1994) – wiring diagram – wiper/washer

Acura Legend (1994) – wiring diagram – wiper/washer

Year of productions:  1994

Wiper/washer

Version 1

Acura Legend – wiring diagram – wiper washer (part 1)
Acura Legend – wiring diagram – wiper washer (part 2)

Version 2

Acura Legend – wiring diagram – wiper washer (part 1)
Acura Legend – wiring diagram – wiper washer (part 2)

WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
