Acura Vigor (1994) – wiring diagrams – lamp out warning

Acura Vigor (1994) – wiring diagrams – lamp out warning

Year of productions:  1994

Lamp out warning

Acura Vigor – wiring diagram – lamp out warning (part 1)
Acura Vigor – wiring diagram – lamp out warning (part 2)



WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
