Dacia Dokker – fuse box diagram
Year of production:
Passenger compartment
| № | Component |
|---|---|
| A | Electric rear window |
| B | Electric door mirrors |
| C | LPG circuit shut-off or LPG circuit and petrol fuel circuit shut-off |
| 1 | Front electric window |
| 2 | Left-hand main beam headlight |
| 3 | Right-hand main beam headlight |
| 4 | Left-hand dipped beam headlight |
| 5 | Right-hand dipped beam headlight |
| 6 | Left-hand side lights |
| 7 | Right-hand side lights |
| 8 | Rear accessories socket |
| 9 | Rear fog lights |
| 10 | Horn |
| 11 | Automatic door locking |
| 12 | ESC |
| 13 | Courtesy light |
| 14 | ABS-ESC |
| 15 | Reverse gear, windscreen wipe |
| 16 | Cruise control/Speed limiter, rear-view mirror, unfastened seat belt warning, parking distance control |
| 17 | Daytime running lights |
| 18 | Fuel pump |
| 19 | Injection |
| 20 | Airbag |
| 21 | Heated seats |
| 22 | Power-assisted steering |
| 23 | Location reserved for additional equipment. |
| 24 | Direction indicator light |
| 25 | Passenger compartment ECU |
| 26 | Passenger compartment ECU |
| 27 | Steering column control |
| 28 | Steering column control |
| 29 | Location reserved for additional equipment |
| 30 | Instrument panel |
| 31 | Radio |
| 32 | Starter |
| 33 | Windscreen wiper |
| 34 | Passenger compartment ventilation |
| 35 | Cigar lighter |
| 36 | Diagnostic socket |
| 37 | Defrosting rearview mirror |
| 38 | Front fog lights |
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
